General Specs |
| Width (in.) | 40.38 |
| Height (in.) | 12 |
| Duct Size (in.) | 8 |
| Depth (in.) | 19.25 |
| Collection | Monsoon |
| Color | Stainless Steel |
| Appliance Fit Width (cm.) | 103 |
| Manufacturer Warranty | 3 Years Parts / 1 Year Labor |
| Color Finish Name | Stainless Steel |
| Range Hood Type | Insert |
| ADA Compliant | Yes |
| ENERGY STAR Certified | No |
| Appliance Fit Width (in.) | 42 |
| Smart Compatible | Yes |
| Maximum CFM | 700 |
| Bulb Type | LED |
| Grease Filter Type | Baffle |
| Sones Rating | 0.8 - 6 |
| Fan Speed Options | 6 |
| Height Above Cooktop | 24 - 36 |
| Width (cm) | 102.57 |
| Height (cm.) | 30.48 |
| Depth (cm.) | 48.9 |
| Height Above Cooktop Centimeter | 60.96 - 91.44 |
| Voltage | 120 |
| Amp | 5 |
| Frequency | 60 |
| Range Hood Features | Wi-Fi Capable, Smart Compatible, App Capable |
| Noise Level (Sones) | Standard - (High) |
| Ventilation Type | Ducted |
More Attributes: |
Blower Performance: |
| Blower CFM (Min. - Max.) | 200 - 700 |
| ACT 590 CFM (Min. - Max.) | 200 - 590 |
| ACT 390 CFM (Min. - Max.) | 200 - 390 |
| ACT 290 CFM (Min. - Max.) | 200 - 290 |
| Optional Dual Blower (Min. - Max.) | 300 - 1,300 |
Features: |
| Zephyr Connect App Compatible | Yes |
| Alexa & Google Home Compatible | Yes |
| ACT™ Technology | Single Blower Only |
| Controls | Proximity Touch |
| Auto Delay-Off | Yes |
| CleanAir Function | Yes |
| Lighting | LumiLight LED, 6W x2 |
| Tri-Level Lighting | Yes |
| Filters | Pro Baffle x2 |
| Removable Grease Tray | Yes |
| ADA Compliant | Yes, with Zephyr Connect or Remote |
Duct Specifications: |
| Vertical Single Internal Blower | 8” Round |
| Horizontal Single Internal Blower | 8” Round |
| Vertical Dual Internal Blower | 10” Round |
| Horizontal Dual Internal Blower | NA |
AC Power: |
| AC POWER (Single Blower) | 120V, 60Hz at Max. 5A |
| AC POWER (Dual Blower) | 120V, 60Hz at Max. 8A |
Optional Accessories: |
| Wireless Remote Control | 14000005 |
| Dual Internal Blower | PBD-1300B |
| Make-Up Air Kit (Single Blower) | MUA008A |
| Make-Up Air Kit (Dual Blower) | MUA010A |
